Shandong Gold Lead Machinery Co., Ltd.
FRP Rebar / Rock Bolt Production Line
PRODUCT PARAMETERS
Description
FRP Rebar / Rock Bolt Production Line is an automated production system designed for manufacturing various specifications of fiber reinforced composite rebars and rock bolts.
The production line integrates multiple processes including roving guiding, resin impregnation, preforming, winding, heating curing, pulling, fixed-length cutting and product collection. It provides efficient and stable production solutions for composite reinforcement materials with high strength, corrosion resistance and lightweight characteristics.
Product Features
1. Automated Production Process
The machine automatically completes roving guiding, impregnation, preforming, winding, heating curing, pulling, fixed-length cutting and product collection.
2. Wide Application Range
Designed for producing various specifications of FRP composite rebars and rock bolts.
3. Stable & Reliable Operation
Advanced mechanical structure ensures continuous production with stable performance.
4. High Efficiency Manufacturing
Integrated production process improves efficiency and reduces manual operation requirements.
5. Flexible Configuration
Different production configurations are available according to customer requirements.
One-line Type FRP Rock Bolt Production Line:
| Parameter | Specification |
|---|---|
| Total Power | 44.8 kW |
| No. of Winding Head | 1 |
| Winding Diameter | Max. 32 mm |
| Clamping Length | 1200 mm |
| Clamping Width | 215 mm |
| Traction Force | Max. 40 kN |
| Traction Speed | 0.1-1.5 m/min |
| Central Height | 1000 mm |
Two-lines Type FRP Rebar Production Line:
| Parameter | Specification |
|---|---|
| Total Power | 64 kW |
| No. of Winding Head | 2 |
| Winding Diameter | 16-26 mm |
| Clamping Length | 1200 mm |
| Clamping Width | 500 mm |
| Traction Force | Max. 40 kN |
| Traction Speed | 0.1-1.0 m/min |
| Central Height | 1000 mm |
FAQs
What types of products can we offer?
We provide complete production solutions for composite material manufacturing, including FRP pultrusion production lines, FRP rebar production lines, CFRP pultrusion machines, winding and braiding production lines, and related auxiliary equipment. We also offer customized equipment solutions according to different application requirements.
What industries are your machines suitable for?
Our equipment is widely used in construction, infrastructure, transportation, renewable energy, aerospace, marine engineering, and other composite material application fields. We continuously develop reliable solutions to meet the needs of different industries.
Can the equipment be customized according to our requirements?
Yes. We provide OEM and customized manufacturing services. According to your product specifications, production capacity requirements, and factory conditions, our engineering team can design and optimize the equipment configuration to achieve the best production performance.
What is the ordering process?
The ordering process usually includes technical communication, solution confirmation, quotation, contract signing, equipment production, factory inspection, and shipment. We will keep close communication with customers throughout the project to ensure smooth delivery.
What services are included in the after-sales service?
We provide comprehensive after-sales support, including equipment installation guidance, operation training, technical consultation, and maintenance assistance. Our professional team is always available to help customers improve production efficiency and ensure stable equipment operation.
